[Single-Sphere Connectors 성능표]
Size I.D |
L |
DΦ |
Allowable Movements in Operation |
Angular Deflection |
Weights-Lbs | |||
FΦ |
Axial |
Axial Elongation |
Transverse Movement | |||||
1¼ |
6 |
1.58 |
2.72 |
0.32 |
0.16 |
0.32 |
15 |
6.6 |
1½ |
6 |
1.58 |
2.72 |
0.32 |
0.16 |
0.32 |
15 |
7.7 |
2 |
6 |
2.05 |
3.39 |
0.32 |
0.20 |
0.32 |
15 |
8.5 |
2½ |
6 |
2.68 |
4.18 |
0.47 |
0.24 |
0.40 |
15 |
12.0 |
3 |
6 |
3.00 |
4.57 |
0.47 |
0.24 |
0.40 |
15 |
14.3 |
4 |
6 |
4.06 |
5.91 |
0.71 |
0.40 |
0.47 |
15 |
15.4 |
5 |
6 |
5.04 |
7.09 |
0.71 |
0.40 |
0.47 |
15 |
24.2 |
6 |
6 |
6.00 |
8.23 |
0.71 |
0.40 |
0.47 |
15 |
30.8 |
8 |
6 |
7.64 |
10.24 |
0.98 |
0.55 |
0.87 |
15 |
46.0 |
10 |
6 |
9.84 |
12.60 |
0.98 |
0.55 |
0.87 |
15 |
55.0 |
12 |
8 |
11.81 |
14.45 |
0.98 |
0.55 |
0.87 |
15 |
84.0 |
14 |
8 |
12.60 |
16.07 |
0.98 |
0.63 |
0.87 |
15 |
110.0 |
16 |
10 |
14.65 |
18.59 |
0.98 |
0.63 |
0.87 |
15 |
132.0 |
18 |
10 |
16.34 |
20.56 |
0.98 |
0.63 |
0.87 |
15 |
195.0 |
20 |
10 |
17.88 |
22.44 |
0.98 |
0.63 |
0.87 |
15 |
195.0 |
|
[Twin-Sphere Connectors 성능표]
Size I.D |
L |
DΦ |
Allowable Movements in Operation |
Angular Deflection |
Weights-Lbs | |||
FΦ |
Axial |
Axial Elongation |
Transverse Movement | |||||
1½ |
6.89 |
1.58 |
2.72 |
1 |
¾ |
1 |
30 |
7.0 |
2 |
6.89 |
2.05 |
3.39 |
1 |
¾ |
1 |
30 |
8.5 |
2½ |
6.89 |
2.68 |
4.18 |
1 |
¾ |
1 |
30 |
12.8 |
3 |
6.89 |
3.00 |
4.57 |
1 |
¾ |
1¼ |
30 |
14.3 |
4 |
8.86 |
4.06 |
5.91 |
1¼ |
1 |
1¼ |
30 |
20.0 |
5 |
8.86 |
5.04 |
7.09 |
1¼ |
1 |
1¼ |
30 |
25.8 |
6 |
8.86 |
6.00 |
8.23 |
1¼ |
1 |
1⅜ |
30 |
29.0 |
8 |
12.80 |
7.64 |
10.24 |
1½ |
1 |
1⅜ |
30 |
45.0 |
10 |
12.80 |
9.84 |
12.60 |
1½ |
1 |
1⅜ |
30 |
62.5 |
12 |
12.80 |
11.81 |
14.45 |
1½ |
1 |
1⅜ |
30 |
95.0 |
|
가격과 규격 주문은 전화나 이메일로 해 주시면 감사하겠습니다.
